EF high beam problems

Recommended Posts

the relays in front of your over flow bottle ,2x are for low beam 2x are for hi beam ,but it wont be them ,there is alittle tin with either 2x thick yellow wires going to it ,this is the hi beam biometalic strip, replace this and all will be well!

Share this post


Link to post
Share on other sites

hi peoples  my xh has just started this crap last night of flashing hi beam and it only does if I let it idle for a couple of minutes.   when on the h/way travelling an hi beam is on its fine

so doctor rev do you think it will be the tin box doing this or light switch or  something else  could it be heat related due lack of air in the bay when stationary? any ideas of help will be apprenticed as my mechanical knowledge is zero

cheers demmo

Share this post


Link to post
Share on other sites

man I lay $10 bucks on the little tin gigger, I worked for ford for many years I must have replaced 100 of then ,also if you have fitted 100wat bulbs get rid of the little 30amp relays and fit 50wat plus

Share this post


Link to post
Share on other sites

thanks rev got hold of the "tin gigger " tonight so will fit 2moz  if I can loose enough grape juice to be able too see straight that is              don't have 100 watt lights ute is all standard ford factory   so hope you are right an sorry think I drank your 10 bucks + already haha  so I owe ya

cheers demmo

Share this post


Link to post
Share on other sites

If your alternator isn't charging properly - outputting at a lower voltage, this will in turn cause the current draw of any accessory loads to increase,

as the battery charge is slowly depleted.



If the alternator has dead diodes, then it's amperage capacity will be reduced, thus will dull the lights, slow the power windows,

(and in extreme cases, can blow fuses) etc.



Dead diodes and/or capacitor, or faulty reg, will also cause AC interference/ripple into the vehicles electrical system - since an alternator output, is a rectified 3phase AC power source.

This interference can upset vehicle electronics, causing all manner of weird things to happen - depending on the functionality of various sensors, the ECU itself, etc.



ie, - some sensors generate their own AC output, which the ECU expects to see.

A faulty alternator can mimic sensor outputs and confuse the ECU, without ever logging any fault codes.



Further example -

A faulty alternator could have AC ripple from a voltage regulator, that exposes itself when the headlights are turned on at idle.

The fuel injection system could then see the ripple as engine RPM and began injecting mass amounts of fuel.



Always verify your alternator operation first, when chasing oddball electrical faults.

(hard to do properly, without access to an oscilloscope)

Share this post


Link to post
Share on other sites

thankyou for the info Dave    I didn't  think  of the alternator as I have never had one die on me so  now before I replace the tin gigger  I will have a play and  see if ac triggers it  have a couple of 100 watt spots I  can plug in as well should be interesting to  see what happens.  my first thought was that it be heat related due to no air movement under the bonnet when stationary as the xh has no grill and the bay  is very enclosed with sump guard  restricting air in low down under bumper so when stationary with fans not on there is no air movement.

anyway thanks again for info  always good to learn something new to keep the brain awake

cheers demmo

Share this post


Link to post
Share on other sites

ok  rev was on the money replaced the tin gigger  an all works fine.  not sure how long as the old unit was quite warm while lights were flicking on/off  the replacement also is quite warm although the lights work as they should.  so is it normal for  do these units to  heat up when in use.   anyway all good for now  thanks for the reply's guys

cheers demmo

Share this post


Link to post
Share on other sites

whats in the little tin box is 2 contact points and a strip of copper ,what happens is as the voltage makes the wiring hot it also affects the copper strip, making it heat up and pull the contacts ,or breakers apart causing this sudden off or flashing affect ,a new will prob make it for 6 months before it to goes poooo!

Share this post


Link to post
Share on other sites
On 7/6/2014 at 8:52 PM, revhead said:

whats in the little tin box is 2 contact points and a strip of copper ,what happens is as the voltage makes the wiring hot it also affects the copper strip, making it heat up and pull the contacts ,or breakers apart causing this sudden off or flashing affect ,a new will prob make it for 6 months before it to goes poooo!



This explanation is not entirely correct, electrically. It does explain it and gets the message accross to most people, though in electrical law it is incorrect.

Voltage does not, will not, and never will be the cause of heat in wiring, or anything else for that matter.

It is Current (Amps) that creates the heat, the more current, the more heat, and a bi-metal strip is constructed of 2 dis-similar metals which have different characteristics at diferent temps. The expansion of those 2 metals (caused by the flow of current) increase at different rates, meaning one will expand more than another. Once the pre-set temp cut'-out (max current) has been reached, the  metal of the bi-metal strip which expands more will spring the opposite direction to where it was. This opens the contacts in the circuit and disconnection occurs. Current is now broken, the metal cools and resets over time and the cable/elec equip has been protected from over heating or worse, fire.
