XD Heater vacuum diagram.

[MNTL.XD 3,831]

Hey guys, been surfing the net over the last few days, trying to find any info on XD heater vacuum lines with absolutely no luck, i ended up going to a wrecker and pulling apart a couple of dash's to find where the hell they go so i can put it all back together after replacing all the dead 30 year old foam. So i thought i'd draw up a diagram for future reference. Figured i'd put it on here too to save anyone else the hassle of working it out for themselves, cheers.



The foam was in pretty bad condition.









Cost about $30 from Clarke Rubber for everything needed to fix it all including internal doors.











... and the diagram needed to put it all back together, i wasn't able to put it back the way it was originally because they'd been put in wrong last time so i only had windscreen demist but no other controls were working, hope it's fixed now, and hope the diagram is useful to someone else too.



[MNTL.XD 3,831]

** On a side note, this is to suit XD without aircon. **



I have done the white hose in pink so it can be seen.

[NZXD 2,328]

Just what I was looking for, I'm just about to do my heater.

Cheers mate.

[bear351c 10,356]

Good work, thanks for sharing.

[Stevo540 20]

Hi there,is the diagram still avaliable?I can't seem to see any photos.i'm about to put in my dash but have no idea where these hoses re attach to.

[bear351c 10,356]

Photos and picture are still here...??  Are you getting the PhotoFucket logo.?

On 9/4/2013 at 3:57 PM, MNTL.XD said:

... and the diagram needed to put it all back together, i wasn't able to put it back the way it was originally because they'd been put in wrong last time so i only had windscreen demist but no other controls were working, hope it's fixed now, and hope the diagram is useful to someone else too.





As Paul mentioned, this an XD without Aircon.

[Stevo540 20]

7 hours ago, bear351c said:

Photos and picture are still here...??  Are you getting the PhotoFucket logo.?



As Paul mentioned, this an XD without Aircon.

Yeah thats exactly whats showing up,damn annoying

[CHESTNUTXE 7,632]

lets bring this thread to light as its one of the last jobs to fix on the xe ,my heater does work,outside air too,but its stuck on windscreen by default as dave has said,fan switch dont work,and suction dont work either,so where should i start looking without ripping it all apart again,or can i manualy stop the outside air from coming in cause im getting a bit of engine bay fumes.

[deankxf 20,743]

24 minutes ago, CHESTNUTXE said:

lets bring this thread to light as its one of the last jobs to fix on the xe ,my heater does work,outside air too,but its stuck on windscreen by default as dave has said,fan switch dont work,and suction dont work either,so where should i start looking without ripping it all apart again,or can i manualy stop the outside air from coming in cause im getting a bit of engine bay fumes.



where the heater box seals to the plenum is where you will get air bypassing the heater box, but it's from the wiper cowel vent, so shouldn't be engine fumes up there really.

the part in the pick where the quick grip clamp is replacing the seal




i haven't got time to read the thread below, but there's some more info to look at.



[CHESTNUTXE 7,632]

yeah i read all those.

[CHESTNUTXE 7,632]

the hoses are all hooked up but still nothing ,when i installed the radio i guess while it was all out that was the time to fix it ,but who could i take it too ,to fix it properly ? a auto electrician ? or someone else.or take it apart again and start testing stuff one by one,sounds like a massive job .

[Joe rop 0]

Hi guys is it easy to convert it to a aircon unit

what’s involved
